Sensitivity
20-80Mv, 1Pa(94Dbspl) at 6 mm, 1KHz
Impedance
Less than 600 ohm
Directivity
Nosie canceling
Frequency
Within RTCA/DO-214, 100-10,000Hz
Operation Voltage
8-16V, (470 ohm bias resistor)
Standard operation voltage
8V (470 ohm bias resistor)
Current consumption
10Ma max at standard operation Voltage.
Sensitivity Reduction
Within -3dB
Noise level
Less than 1 mV
Termination
Mates with standard U-173/U audio connector
Dimansions
1.72”L x 0.77”H x 0.49”W
Weight
Less than 10g
